Carbon Fiber Cutting Press

Carbon fiber cutting press is applicable to cutting carbon fiber sheet, carbon fiber woven, cloth carbon fiber, carbon fiber fabric and other products.

Carbon Fiber Cutting Press
Carbon Fiber Cutting Press

Key Feature
1. Materials can be cut in sheet or roll although in several layers.
2. Dies can be set with the upper beam, on the table blade or on the material. Any shapes can be cut by the normal die.
3. The machine is equipped with hydraulic power and qualified components.
4. Different feed modes can be chosen from: manual sliding tables, single and double sliding tables, roll feed system, clamp feed system and so on.
5. The details of this machine are listed as follows. Also, the machine can be improved to meet your expectations.
Model: GRBC-25T to 500T
Max cutting force (T): 25T to 500T
Distance between upper press board and worktable (mm): 50-240
Cutting area (mm): 1250×600, 700, 800, 900, 1000, 1200, 1500
1470×600, 700, 800, 900, 1000, 1200, 1500
1600×600, 700, 800, 900, 1000, 1200, 1500
Motor power: 1.5 to 22KW
Net weight (KG): 1600 to 16500, 1700 to 17500, 1800 to 18500
