Precise four-column hydraulic beam cutting Press

As a leading professional die cutting machine manufacturer and designer ,Gerson machinery have many models of Precise 4-column hydraulic beam cutting Press which for the large area die cutting soft and rigid material :

Precise four-column hydraulic beam cutting Press
Precise four-column hydraulic beam cutting Press

1. This  die cutting machine is widely used for cutting of non-metal materials in various industries by cutting die.
2. Adopt double oil cylinder, precise double-crank connecting rod mechanism, which can guarantee that the cutting depth at every cutting position is the same.
3. With special setting mechanism, and equipped with cutting die and cutting depth setting, the travel adjustment is simple and accurate.
4. The pressing board of cutting carries out slow cutting when it contacts the die cutter, which can make that there is no size error between the uppermost layer and lowermost layer of cut materials.
5. The central oil supply automatic lubricating system guarantees machine precision and prolongs service life of machine.

Model GRB(C)-25T to 500T
Max cutting force(T) From 25 Tons to 500 Tons
Range between working table 50-240mm (Upper to Bottom Table)
Stroke Adjustment 0-170mm
Cutting area(mm) (500-3000)X(1000-3000)mm
Based on your material and die
Example: 1600X600mm etc.,
Motor power 1.5 to 22KW
Electric Power 220V/380V/415V,50-60hz etc.,
Machine Net weight (KG) 1600 to 16500
1700 to 17500

Gerson can make the cutting machine according to your specifical requirement :such as cutting force power,worktable size,motor,etc.,
