Vulcanizing Fiber cutting machine

Gerson Vulcanizing Fiber cutting machine is die cutting machine for vulcanizing fiber material and products

Vulcanizing Fiber cutting machine
Vulcanizing Fiber cutting machine

Vulcanized fibre is a laminated plastic composed of only cellulose or high purity cellulose papers. The material is a tough, resilient, hornlike material that is lighter than aluminium, tougher than leather, and stiffer than most thermoplastics.Mechanically excellent punching, forming, machining and many other unique properties.

Using Gerson Vulcanizing Fiber cutting machine can be die cutting any shapes with cutting dies .

For different Vulcanizing Fiber size and thickness ,There have many cutting machine for choice.

1.For cutting small Vulcanizing Fiber ,The cutting table from 650×330mm to 1000×500mm ,the cutting power from 8 tonnages to 30 tonnages.

Model GSB-8/10,GSB-2C,GR,GRA
Maximum   Cutting Force 8Tons,10,12,14,15,16,18,20,22,25,27,28,30 ton
Cutting speed 0.085m/s
Adjustable stroke 5-180mm
Tension distance 60-190mm
Cuttting table size 650×330mm,900×430mm,1000×500mm
size 660×780×1500mm to 1350×1180×1700mm
Motor Power 0.75KW to 1.5Kw
Net Weight (N.W.) 550Kgs to 1200kgs













2.For big area and hign productivity,The cutting table can be normal from 1250×600mm to 2500×2500mm,Cutting power from 25 tonnages to 500 tonnages.Pneumatic adjustable tool rails,Board rails to clamp cutting boards to press head,Material feed rollers,Automatic knock-out systems are available.

Model No. GRB(C)-25T to 500T
Max cutting Power(Ton) From 25 tons to 500 tons
Distance between upper press board andworktable(mm) 50-240mm
Cutting  table area(mm) 1250×600,700,800,900,1000,1200, 1500mm
1470×600,700,800,900,1000,1200, 1500mm
1600×600,700,800,900,1000,1200, 1500mm
Motor power(Kw) 1.5 to 22KW
Machine Net weight (KG) 1600 to 16500kgs
1700 to 17500kgs
1800 to 18500kgs
