F50 die cutting machine with swing head clicker press

F50 die cutting machine with swing head clicker press using for cutting non-metallic material including aluminum foil,sound insulation sheet,leather carrier etc.,

F50 die cutting machine with swing head clicker press
F50 die cutting machine with swing head clicker press

This typical clicker press is one of Gerson machinery most types die-cutting equipment.These equipment is quite simple but robust body in order that could cutting-out sheet board.

These die clicker stamping force has mini 5 ton to 30 ton etc.,.Gerson machinery also have other little and large pressure for production plants, home, lab,store cutting purchasement in order that could to meet the requirements of for production solution

The machinery has best speed for die-cutting and low energy exhaust with slight sound.

These machinery is quite easy to operate by workers hand and twin workers hand to handle should be sure assurance.

The rotating arm cutting machine is high solution cutting with mini die tool for sheet board.
These clicking press have material table up to 20″ x 47″ and head sizes up to 24″ in width.

Gerson can custom build any machine to meet your request.welcome to contact us .

Model  F45/GR-20C F50/GR-27C F60/GR-27C/1 F70/GR-27C/2
Max. cutting power 20 ton 27 ton  27 ton 27 ton
Maximum stroke(mm) 80 100 100  100
Cutting table(mm)  900 x 430  900 x 450 1000 x 500 1200 x 500
Arm width(mm)  370 370 500/600 500/600
Motor power HP. 1 HP. 1,5 HP. 1,5 HP. 1,5
Net weight with oil Kg. 570 Kg. 780 Kg. 840 Kg. 910
Sizes about (mm)  1000 x 900
h. 935		 900 x 1000
h. 1370		 1000 x 1000
h. 1370		  1200 x 1030
h. 1370
Sizes sea packing(mm) 1050 x 1085
h. 1500		 1050 x 1150
h. 1570		 1150 x 1150
h. 1570		 1350 x 1180
h. 1570
Gross weight and volume with sea packing Kg. 640
m3 1,7		 Kg. 900
m3 1,90		 Kg. 980
m3 2,10		 Kg. 1055
m3 2,50
