120 Ton Beam Press with with Roller Conveyor

Gerson 120 ton beam press with a roller conveyor is a specialized industrial die cutting machine used for various high-force pressing or cutting applications, often in automated or semi-automated production lines.See the below details:

120 Ton Beam Press with with Roller Conveyor
120 Ton Beam Press with with Roller Conveyor

Beam Press (Die Cutting Press): This refers to a type of press where the cutting or pressing force is applied by a “beam” or platen that moves up and down.

120-Ton Capacity: This indicates the maximum force the press can exert, which is 120 tons (or approximately 240,000 pounds). This high tonnage allows it to cut or form thick, dense, or multiple layers of materials ,So it can die cutting shapes from various materials like textiles, foam, rubber,metal, leather, gaskets, composites, plastics, paper, and more etc.,

Roller Conveyor:The roller conveyor system is integrated with the press to facilitate the efficient movement of materials into and out of the press’s working area. This automation significantly increases production speed and reduces manual labor.

Key Features and Benefits of a 120-Ton Beam Press with Roller Conveyor:

  • High Production Volume: Automation with the conveyor allows for continuous or rapid processing of materials.
  • Increased Efficiency: Reduced manual handling, faster cycle times, and automated material flow.
  • Precision: Many systems incorporate servo-driven components and PLC controls for accurate material positioning and cutting depth.
  • Versatility: Can handle a wide range of materials and applications depending on the tooling (dies) used.
  • Safety: Automated systems often include safety features like light curtains and guarded areas to protect operators.
  • Material Optimization: Advanced systems can include nesting software to minimize material waste.

120-ton beam press specifications

Specification 120-Ton Beam Press Notes
Model Series GRB(C)-120 . “120T” indicates 120 Tons.
Max Cutting Force 120 Tons This is the rated maximum force the press can exert.
Max Daylight (Open Height) 10 – 19 inches (254 – 483 mm) Distance between bolster plate and ram when fully open. Accommodates tooling + material.
Stroke Adjustment 0 – 12 inches (0 – 305 mm) Range of adjustable ram travel; allows optimization for different die heights.
Cutting Area (Bed Size) (40-80) x (25-40) inches (1016-2032 mm) x (635-1016 mm) Example: 60 x 30 inches (1524 x 762 mm). Varies significantly based on press design by Gerson.
Motor Power 10 – 30 HP (7.5 – 22 kW) Power for the hydraulic pump. Higher HP generally means faster cycles.
Electric Power 208V/230V/460V/575V, 3 Phase, 50-60Hz Varies by region as your request.
Machine Net Weight 10,000 – 25,000 lbs (4,500 – 11,340 kg) Varies greatly based on frame construction, bed size, and components.
Strokes Per Minute (SPM) 10 – 40 SPM Depends on stroke length, material, and specific press design.
Hydraulic Pressure 2,750 – 3,800 PSI (190 – 262 bar) Internal operating pressure of the hydraulic system.
Throat Depth 8 – 24 inches (203 – 610 mm) Distance from the ram center to the frame. Crucial for part size.
