This Gerson die cutting machine is great for BOPS,HIPS,PS,PP,PVC,PET,ABS disposable plastic plates and bowls tableware,Biodegradable Tableware, Food Containers etc.,
Features：
1.Adopt the balanceable set of three cylinders , which can accelerate the stroke speed between top and bottom and improve the production efficiency..
2.The upper mold is attached with rotary plate that can move freely, protecting the lifetime of cutting die and cutting board
3.The oil-path can control the cooling effect; you will not install the cooling machine again, reducing the trouble of equipping pipe.
4.Bending moving arms transfer, feed the cutting to the cutting point, quickly, accurately and stably Which can avoid oil leakege when traditional oil cylinder feeding and prevent feeding cutting damage caused by oil seal wear decompression problem.
| Model | GRK-180 | GRK-180/ | GRK-300 | ||
| Maximum Cutting Force | 180T | 180T | 300T | ||
| Stroke adjustment | 10×250mm | ||||
| Working Area | 1400×720mm | 1600×850mm | 2300×1200mm | ||
| Motor power | 7.5HP | 7.5HP | 10HP | ||
| Overall dimension(mm) | 2300x2000x 2000 | 2300x2100x2300 | 2350x2850x3000 | ||
| weight | 63000kg | 6800kg | 13000kg | ||
