die cutting machine for plastic blister packing/packaging
Gerson have many die cutting machine models for plastic blister packing/packaging including the Blister,Clamshell,Plastic clamshell,Clamshell packaging etc.,: Die cutting Materials:PVC,PP,PS,PET,APET,PETG,PLA,etc
die cutting machine for plastic blister packing/packaging
This beam press is common used for die cutting plastic blister packing/packaging. If you need to die cut the above material or similar material including:Textiles, Leather, Cork, Rubber, Glass, Fiber, Plastics, Packing, Paper, Gaskets, Floor Tiles, Felt, Sponge, Hardboard, Upholstery, Carpet,please contact Gerson machienry.
This Beam press systems can be added with a range of ancillary equipment to enhance your productivity:
Inboard and outboard material conveyors
Manual tool rails
Pneumatic adjustable tool rails
Board rails to clamp cutting board to press head
Material feed rollers
Automatic knock-out systems
Material alignment
Automatic cutting pad shifter
Edge sensing
Automatic tool changing
Tool racking
Material feed gantries and many other options.
Model
GRB(C)-25T to 500T
Max cutting force(T)
From 25 Tons to 500 Tons
Range between working table
50-240mm (Upper to Bottom Table)
Stroke Adjustment
0-170mm
Cutting area(mm)
(500-3000)X(500-3000)mm
Based on your material and die
Example: 1600X700mm etc.,
Motor power
1.5 to 22KW
Electric Power
220V/380V/415V,50-60hz etc.,
Machine Net weight (KG)
1600 to 16500
1700 to 17500
Gerson can make die cutting machine press according to your specifical requirement :such as cutting force power,worktable size,motor,feeding type etc.,
