F60 Clicker Press Hydraulic Swing Arm Cutting Press

F60 Clicker Press Hydraulic Swing Arm Cutting Press is one of swing arm clicker press that used in many industry.There also have F50,F60,F70 serial cutting machine.

F60 Clicker Press Hydraulic Swing Arm Cutting Press
F60 Clicker Press Hydraulic Swing Arm Cutting Press

Very easy operated by twin hand by the worker,and do not special trainging.Very fast and safe.

The cutting force ,table size etc., can be custom built based on request.

It is used in automatic stroke end with pressure switch to use cutting-knives of different heights, without any adjustment. So it is easy for operation.

Electronic die cutter :
This simple and innovative system permits die cutting of various depths without the need for changing adjustment settings.

This system also permits working with very small dies without cutting into the cutting block.

If you want to find more die cutting machine ,please contact us .

Model F45/GR-20CF50/GR-27CF60/GR-27C/1F70/GR-27C/2
Max. cutting power20 ton27 ton 27 ton27 ton
Maximum stroke(mm)80100100 100
Cutting table(mm) 900 x 430 900 x 4501000 x 5001200 x 500
Arm width(mm) 370370500/600500/600
Motor powerHP. 1HP. 1,5HP. 1,5HP. 1,5
Net weight with oilKg. 570Kg. 780Kg. 840Kg. 910
Sizes about (mm) 1000 x 900
h. 935		900 x 1000
h. 1370		1000 x 1000
h. 1370		 1200 x 1030
h. 1370
Sizes sea packing(mm)1050 x 1085
h. 1500		1050 x 1150
h. 1570		1150 x 1150
h. 1570		1350 x 1180
h. 1570
Gross weight and volume with sea packingKg. 640
m3 1,7		Kg. 900
m3 1,90		Kg. 980
m3 2,10		Kg. 1055
m3 2,50
