1.The upper receding beam or head can be moved forwards and backwards and the distance is fine adjustable for the convenience of placing cutting materials.
2.Cutting area same as the beam/head area ,so it is great for large cutting dies.
3.The cutting material remains stationary during the receding cutting.
4.Larger head, bed and tonnage needs can be custom ordered.
Model
Maximum Cutting power(ton)
Area of work table(mm)
Press Board
Stroke range
Distance between upper pressing board and worktable
Motor power
Machine dimensions（mm）
Net weight
GRH-35
350KN(35T)
1600*610mm
1600*600mm
0-110mm
60-160mm
3KW
2320*1400*1520mm
2400kg
GRH-50
500KN(50T)
1600*610mm
1600*600mm
0-110mm
60-160mm
4KW
2320*1600*1720mm
4000kg
GRH-80
800KN(80T)
1600*820mm
1600*800mm
0-120mm
60-180mm
4KW
2320*1600*1720mm
5500kg
GRH-120
1200KN(120T)
1600*820mm
1600*800mm
0-120mm
60-180mm
5.5KW
2320*1600*1720mm
6500kg
**Cutting Force more than 120T or upwards can custom made.
**Cutting Bed more than 1600x800mm or upwards can custom made.
