Gerson small hydraulic die cutter is die cutting machine with mini cutting force and cutting table .Gerson have 8 ton small hydraulic die cutting machine.This small hydraulic die cutter can die cutting most small pieces material including :fabric,leather,paper,plastic,paperboard,fibre,textile,cork etc., It is for lab using or industry use.
small hydraulic die cutter
1.Easy to operate with two hands using swing arm and button press.
2.Economic cost and stable working function.
3.Two hands switches operate to ensure the operator is safe and easy.
4.The position of the swing arm is adjusted by the upper handwheel on the top of clicking press,which can obtain the best cutting position ,which can increase work efficiency and prolong the service life of cutting dies or boards.
5.More cutting force and cutting table is avaliable .and also have 5 ton mechanical press.
Model
GSB-8
GSB-10
Maximum Cutting Force
8Tons
10Tons
Cutting speed
0.085m/s
0.085m/s
Adjustable stroke
5-60mm
5-60mm
Tension distance
60-130mm
60-130mm
Cuttting table size
650×330mm
650×330mm
size
660×780×1500mm
660×780×1500mm
Motor Power
0.75KW
0.75KW
Net Weight (N.W.)
550Kgs
600Kgs
