35T traveling head hydraulic cutting machine is built by Gerson machine .This hydraulic cutting machine is hydraulic driven with 35 ton cutting pressure.
Key Feature
1. Called traveling head hydraulic cutting press or just traveling head press, the machine is able to cut leather, fabric, rubber, fiberglass and many other similar materials.
2. Operators shall have a wide sphere of vision due to the flexible travelling head.
3. The traveling head can be operated by operators or just run automatically under the CNC control. Both of them would reach high output with small cycle interval.
4. Double oil cylinders, four-oriented design, auto balance and lubrication system make up the good-qualified cutting machine, which presents long-term excellent performance in cutting accuracy.
5. Cutting force ranges from 25T to 150T, cutting table area and other components can be customized.
| Model | GRM-25,30,40,50,60,80,100 |
| Max Cutting Force | 25 to 100 tons |
| Cutting table Widths | 1800~2500mm or more |
| Cutting Head/Movable trolley | 500 x 500mm up to 1000 x 1000mm |
| Gerson can make the cutting machine according to your specifical requirement :such as cutting force power,worktable size,motor,etc., | |
