Gerson clicker press with high stroke and large open daylight is die cutting machine designed for cutting big height requirement of the material products.
1.The clicker press stroke and open daylight can custom built according to the production requirement.Also the cuttting force and cutting table size can custom built.
2.The clicker press head descends under hydraulic power to die cut shape from single or multiple layers of material by cutting knife/die.
3.It is good for die cutting the soft and semi-rigid material including leather,fabric,paper,cardboard,foam,PVC,plastic,ABS,PC film,rubber,cork in sheet or roll .
4.Any other more bigger die cutting machine available.
| Model | GSB,GR,GRA model |
| Maximum Cutting Force | 8-30 tons |
| Cutting speed | 0.085m/s |
| Adjustable stroke | 5-250mm |
| Open Dayight | 60-300mm |
| Cuttting table size | 800,900,1000,1200×400,500mm |
| size | 660×780×1500mm or more |
| Motor Power | 0.75KW,1.1KW |
| Net Weight (N.W.) | 450Kgs-1100Kgs |
