Gerson 18 ton clicker press machine design and manufacture by Gerson.The clicker press is good for die-cut the material such as Shoes Upper,Glover leather,Mobile phone Cases, Small toys, Decorative pieces, Clip components, Handbag attachments ,Paper pad,fabric pad etc.,
18 Ton Clicker Press Machine
1.The machine use hydraulic system with top quality component.
2.The machine can move or swing the arm easily and place the die for the next cutting.
3.The press can die cut any shapes by the formed cutting die/knife.
4.The machine head or beam height is controlled by the handwheel and cut adjust the cutting force easily.This 18 ton is the max cutting force.Also other more than 18 ton or less 18T available.
5.Single phase or three phase.Other cutting table size etc.,Any special custom build welcome to contact Gerson.
Model
GR,GRA,GSB model
Maximum Cutting Force
80-300 kn(more large cutting force ,please see the other model)
Cutting speed
0.085m/s
Adjustable stroke
5-180mm
Tension distance
60-250mm
Cuttting table size
800,900,1000,1200×400,500,610mm more
size
660×780×1500mm or more
Motor Power
0.75KW,1.1KW
Net Weight (N.W.)
450Kgs-1100Kgs
