25 ton clicker press is 25T ton pressure die cutting press used for cutting semi-rigid material also it can be used for cutting soft material incluidng leather ,paper,cardboard,foam,eva,pvc,epe,plastic ,rubber ,fabric etc.,
1.25 ton hydraulic press with 1000mm plus 500mm cutting table size.Gerson also have 8 ton,10 ton,12 ton,15 ton,16 ton, 20 ton ,22 ton,25 ton,27 ton,28ton clicker press.The cutting table size can custom build based on your material.
2.This 25 ton press ,operated by double hand ,reliable and safe.Just put the material on the cutting bed.Then put the die tool on the material where you want to cut out .move the upper beam over the die.Then press the pushbutton by your double two hand.The machine will cutting the material out by the die which you want.
3.This is hydraulic driven system ,special design by Gerson .Using top hydraulic parts and components which make sure high qulity and long time using for the press machine.
4.Gerson also have othe press machine ,if you want to know more information ,please contact us at any time.
5.The following specification is for the above model machine. Gerson have others ,you could click the other machine in the web.
| Model | Cutting Table | UP Beam Head | Max Pressure | Net Weight |
| GR-270L | 1000×500 | 610mm | 25T–245Kn | 1050 (kg) |
| GR-270M | 1000×500 | 500mm | 25T–245Kn | 1030 (kg) |
| GR-270C | 900×450 | 500mm | 25T–245Kn | 900 (kg) |
| GR-250L | 1000×500 | 370mm | 25T–245Kn | 990 (kg) |
| GR-250M | 900×450 | 370mm | 25T–245Kn | 880 (kg) |
| GR-220L | 1200×500 | 500mm | 22T – 216Kn | 1060 (kg) |
| GR-220M | 900×450 | 370mm | 22T – 216Kn | 880 (kg) |
| GR-220C | 900×430 | 370mm | 22T – 216Kn | 630 (kg) |
| GR-10C | 600×300 | 300mm | 8T – 78 Kn | 430 (kg) |
Electric Supply Voltage: 3 phases×440/415/400/380/220/200V, 50/60 Hz,
Single phase 110v/240V/220V, 50/60 Hz
